UD 30 Drill driver
Corded two-speed, high-rpm drill driver for metal applications
- Chuck clamping range: 2 - 13 mm
- No load RPM: gear 1: 1200 rpm; gear 2: 3300 rpm
- Maximum torque (soft/hard joint): 51 Nm (soft joint)
Technical Data
Chuck clamping range
2 - 13 mm
No load RPM
gear 1: 1200 rpm; gear 2: 3300 rpm
Maximum torque (soft/hard joint)
51 Nm (soft joint)
Number of gears
2
Dimensions (LxWxH)
337 x 86 x 205 mm
Weight
2.4 kg
Triaxial vibration value for drilling into metal (ah,D)
3.5 m/s² 1
Chuck type
Pistol grip, Quick-release chuck 13 mm
- According to the applicable product standard (see Operating Instruction for more details)
Documents
Features & Applications
Features
- Ergonomically designed pistol grip and low weight for maximum comfort during long periods of use
- Very reliable thanks to the extremely rugged casing and robust motor
- Stepless electronic speed control for smooth, gentle starting and screwdriving
- Choice of keyless chuck with spindle lock or robust key chuck
- Keyless quick-release chuck with spindle lock for easy bit changing
Applications
- Drilling in steel and sheet metal
- Drilling in wood with auger bits, paddle bits and Forstner bits
- Various screwdriving jobs
- Use of hole saws (up to 68 mm diameter)
- Driving large-diameter wood screws
For approval or certificate information, please see individual items.
