TE-Y (SDS Max) Metric hammer drill bit
Hammer drill bit TE-Y 14/35 #418303
Premium SDS Max (TE-Y) hammer drill bit with carbide tip for drilling into concrete
- Connection end: TE-Y (SDS-max)
- Base material: Concrete, Masonry, Brick, Sand-lime block
- Working mode: Hammer drilling, Drilling only
premium
Choose options
Diameter
- 14 mm
Working length
- 200 mm
Length
- 350 mm
Pack size
- 1
Quantity
Packs
Total Pieces
1
Discounted net
INR 2,620.00
INR 2,620.00 / 1 each
Technical Data
Connection end
TE-Y (SDS-max)
Base material
Concrete, Masonry, Brick, Sand-lime block
Working mode
Hammer drilling, Drilling only
Head shape
2 cutters
Head material composition
Tungsten carbide
Number of cutting edges
2
Diameter
14 mm
Length
350 mm
Working length
200 mm
Product class
Premium
Features & Applications
Features
- Short transition from carbide tip to helix delivers higher drilling speed
- Trouble-free deep-hole drilling thanks to rapid removal of dust and fragments
- Carbide tip securely embedded in the helix
- Short transition between the drill bit head and flutes for fast drilling
- Carbide tip ruggedly embedded in the steel body
Applications
- Through-holes and penetrations in concrete and masonry in the plumbing, heating and air-conditioning systems installation trades
Related Products
Extension for SDS Max (TE-Y) hammer drill bits - 2 components required (TE-FY extension plus TE-Y-AD adapter)
